Technical Specification
| Size | 2″ to 36” (50 mm to 900 mm) |
| Pressure Rating | PN10, PN16, PN25, Class 150 |
| Design Standard | API 609 Cat A, EN 593 (BS 5155), MSS SP 67 |
Salient Features:
- Enhanced reliability, longer service life
- Tight sealing, Consistent low torque
- Assured shaft sealing
- One-piece blowout-proof Shaft
- Reliable Drive – Positive shaft-disc connection
- Lower resistance to flow – Contoured disc
- Ease of installation
- Integral actuator mounting platform
Versatile Range:
- Pressure ratings: PN10, PN16, PN25 and Class 150
- End connections: Wafer, Lugged, Flanged
- Body materials: Cast Iron, SG Iron, Carbon Steel, SS 304/ CF8, SS 316/ CF8M
- Seat Elastomer options: Black/ White Nitrile, EPDM, Viton, Hypalon, Silicon
- Specials: Long Neck, Extended Stem
