Technical Specification
| Application | Flow connecting or cutting off | |
| Design Standard |
|
|
| F to F Standard | ASME B16.10 | |
| Testing Standard | API 598 | |
| End Connection Standard | ASME B16.5 | |
| Size |
NPS 1/2 to 2 DN 15 to 50 |
|
| Pressure Class Range |
· 600 to 1500 · PN 110 to 260 |
|
| Ends | Flange End, Butt weld | |
| Body |
ASTM A216 Gr.WCB, ASTM A352 LCB, LCC, A217WC9, C5, A351 CF8M, CF3, CF3M, CN7M
|
|
|
13% Cr, 18% Cr 8% Ni, Stellite, Monel, Alloy 20, Bronze
|
|
| Seat Material Options | EPDM (-40°C to 120°C), Nitrile (-34°C to 100°C), PEEK (-50°C to 260°C), PTFE (-200°C to 260°C) | |
| Temperature Limits | Depending on seat material: -200°C to 260°C (PTFE); -50°C to 260°C (PEEK); -40°C to 120°C (EPDM); -34°C to 100°C (Nitrile) | |
| Applications | Water Treatment, Fire Protection, Gas, Petroleum, Chemical, Shipbuilding |
