| Size Range |
2” ~100” + (DN50~DN2500+) |
| Class Range |
150Lb~2500Lb (PN10~PN420) |
| Designs |
Reduced and Full-bore design |
| Design Standard |
API600, API 602,ASME B16.34, API603 |
| End Connection |
RF/ RTJ – ASME B16.5 / B16.47; BW – ASME B16.25 NPT to ANSI B1.20.1 SW to ANSI B16.11 |
| F – F Dimension |
ASME B16.10 (Flanged) Manufacturer’s standard (NPT, SW, NPT x SW) |
| Construction |
Flexible/Solid Wedge |
| Design Features |
BB/ PSB, RS, OS&Y, Emergency Sealant Injection, Vent & Drain, By-pass; DTR |
| Seat Material Options |
Stellite Coated (Cobalt-based), 4140 Stainless Steel, 316 Stainless Steel, Inconel, Monel |
| Temperature Limits |
-196°C to 425°C (Stainless Steel), -29°C to 650°C (Stellite), -100°C to 650°C (Inconel) |
| Special |
NACE, Cryogenic, Extended Stem, Fugitive Emission, Bellow Seal, By-pass |
| Material |
Forged & Cast CS, LTCS, SS, Duplex SS and Exotic Alloy |
| Applications |
Oil & Gas, Gas Pipelines, Coal Seam Gas, Chemicals, Water, Power, Marine, Mining, etc. |
